01 · Machine Design
Custom machines, designed to your exact requirement.
A new machine, an upgrade or a full production line. We design each one to be simple to fabricate and assemble, because that is where cost and time are saved.
Pillar 03 · Industrial & Machine Design
We design the machines that run your business.
Machine, mechanical and industrial design for factory equipment, production lines and plants. Designed, calculated and tested before a single part is cut.
The problem
Many factories run on machines nobody properly designed.
Machines get imported, or built in a hurry on the shop floor, with no drawings, no calculations and no plan. That works until something breaks or you need more output. Then nobody knows how the machine was made or how to change it.
What we do
Engineering first. Fabrication second.
- We design new machines, or improve the ones you already have.
- We test the design on the computer before you spend on materials.
- We give you clear drawings any fabricator can build from.
Capabilities
Four things we do, start to finish.
02 · Testing on Computer
We test the design before you build it.
Finite element simulation shows whether the machine is strong, safe and reliable, while fixing a problem still only means changing a drawing.
03 · Drawings & Documentation
Drawings your fabricator can quote from.
Every dimension, part and material is set out clearly. No guesswork on the shop floor, no disputes over what was agreed, no surprises on the bill.
04 · Factory Layout
Layouts that make the whole plant work better.
We plan where each machine sits, how material flows and where people work, so the plant runs faster and safer with less waste.
Engineering process · requirement → fabrication
How we work with you.
Nothing gets built until it has been designed, calculated and tested on the computer.
Understand your need
We visit your site, hear the problem and agree on what success looks like.
Design the machine in 3D
A 3D concept you can see and approve: sizes, materials and how it all fits together.
Test it on the computer
Simulation checks it is strong, safe and reliable before any steel is bought.
Detailed drawings
A complete drawing pack and parts list: everything a fabricator needs to quote and build.
Build & commissioning
We stay with you through fabrication and start-up. You get more than a file.
Validation · finite element method
Find problems on screen, not on your factory floor.
Before anything is fabricated, we run the design through a computer test. We apply the real weights, forces and heat it will face at work and check where it might bend, crack or fail. Any issue gets fixed on screen, before you've spent on materials.
- Is it strong enough?
- Will it hold its shape under load?
- How long will it last?
- Will it handle heat and vibration?
MAX DISPLACEMENT2.978 mm
MIN0.0 mm
OUTPUT SETLoad restraint
Deliverables
What you walk away with.
Every project ends with a complete package your fabricator, supplier and team can use, not a single file.
01
Manufacturing drawings
Complete drawings your fabricator can build from, with every dimension and detail.
02
Design calculations
The engineering numbers that prove the machine is safe and will do the job.
03
Simulation report
Results from the computer tests, so you and your team can move forward with confidence.
04
Parts list
A full list of every part and material, ready to hand to your supplier for quoting.
05
Factory layout plan
A clear floor plan showing where every machine sits and how work flows through the plant.
06
Support till start-up
We stay on call through fabrication, assembly and start-up, not just the paperwork.
Is this you?
Think of us when you meet…
- 01A factory owner with old or unreliable machines that need replacing or upgrading
- 02A business owner who wants to build their own machines instead of importing
- 03A manufacturer expanding capacity who needs a proper factory layout
- 04Anyone quoting for a project that needs proper drawings and engineering calculations
- 05A business with a working machine but no drawings, which needs to be documented
- 06A factory owner who feels their production line could run faster or smoother
Let's connect
Send us your next machinery challenge.
Tell us what the machine needs to make, move or fix, and how much of it per day. Photos of the current setup help.
